CY-HD01

12寸 标配版

Heavy cargo electric motorcycles have overload capacity, whether it is goods or personnel, can be easily carried, especially suitable for users who often transport major goods to solve the problem of insufficient load capacity of electric vehicles. this heavy cargo electric motorcycle uses 60/72V universal battery design, users can choose the appropriate battery capacity according to their needs, made of high quality materials and parts, through strict quality inspection and safety testing. it is equipped with brake system, anti-skid tires and other safety facilities to ensure more safe and reliable driving, very tough,dynamic and adaptable to all kinds of rough terrain !

详情

参数

Hummer Pickup /17inch · 2000W (Enhanced Version) Configuration List :

Overall dimensions (length*width *height) mm 2200*810*1150 Rated passenger capacity (persons) 1
Battery compartment dimensions (length*width *height) mm 680*280*210 Load capacity (in kilograms) ≤250
Front and rear wheel track (in millimeters 1530 Steepness of the slope ≤22°
Saddle height (in mm) 820 Pre-lamps The former LED headlight
Empty vehicle weight (excluding battery) kg 90
Trailing taillights LED combined taillights
Motortype 17inch hub motor Front hub 1.4*17 Aluminum alloy wheels
Motor power (in kilowatts) 2 Front and rear vacuum tires 90/90-12
Rated voltage V 72V
Front and rear double-tube hydraulic shock absorber Front straight tube 31mm, 720mm high; rear reinforced, 320mm high
Controller 2000 W leadless sinusoidal wave controller Front and rear brakes Front disc brake /Rear disc brake
Maximum torque: N.m 180 Front and rear brake control methods Front and rear handle handbrake
Under-voltage protection value 60V Minimum ground clearance mm 210
Overcurrent protection value 65A Batterytype Lithium battery/ Maintenance-free lead-acid battery
Maximum Design Speed (in kilometers per hour) 65
Battery capacity Lithium battery 72V 120Ah Lead-acid battery 72V 55Ah
Charger / Charging Time Optional model/ Fully charged in 5-10 hours
